| Name of light source: | visible (red) chirped supercontinuum for LIF scans |
| Name of vendor selling or name of group using this source: | Sanders group, UW-Madison |
| Year of initial publication or catalog entry: | 2005 |
| Primary application for which this source was developed: | liquid thermometry |
| References or URLs for relevant information on this source: | J. W. Walewski and S. T. Sanders, Opt. Lett., Vol. 30(18), p. 2394, 2005 |
| Additional information / notes: | Based on a supercontinuum generated in photonic crystal fiber pumped by a Nd micro-chip laser. The continuum is then dispersed in a multi-mode fiber. Applied to rapid LIF excitation scans. The scanning width stated below was limited by the photodetector and could be extended by at least 2000 wavenumbers. |
| Span of the spectrum covered, based on -10dB points [cm-1]: | 5800 |
| Time to cover this range [s]: | 7.0E-8 |
| Spectrum update repetition rate [Hz]: | 25000 |
| Center wavenumber [cm-1]: | 13000 |
| Center wavelength [nm]: | 769.23076923077 |
| Spectral Resolution, best in scan [cm-1]: | 240 |
| Power in TEM00, averaged over 1 s [mW]: | 4 |
| Shortest time spent on 1 spectral resolution element [s]: | 6.6E-9 |
| Physical dimension -- length [mm]: | 600 |
| Physical dimension -- width [mm]: | 400 |
| Physical dimension -- height [mm]: | 1500 |
| Approximate system cost [US$]: | 6000 |
| Data rate [S/s]: | 188500 |
| Duty cycle [%], based on -10dB points: | 0.175% |
| Best spectral resolution [GHz]: | 7200 |
| Best spectral resolution [nm]: | 14.201183431953 |
| Longest coherence length [cm]: | 0.0041666666666667 |
| Spectral tracking linearity [%]: | 227.85714285714% |
| Spectral coverage [nm]: | 343.19526627219 |
| Size [m3]: | 0.36 |
| Initial entry time: | 2006-08-20 12:01:01 |
| Last modified time: | 2006-08-30 14:13:28 |
| Associated image file: |
